Amptec 630BN Ruggedized Failsafe Ohmmeter with Diode Test Capability (20 Ω,200KΩ)

Range: 20 Ω

Nominal Current: 5 mA

Failsafe Current: 8 mA

Resolution: 1 mΩ

Accuracy: ± .02% of reading & range


Range: 200 Ω

Nominal Current: .5 uA

Failsafe Current: 1.8 uA

Resolution: 10 mΩ

Accuracy: ± .02% of reading & range


Range: 2K Ω

Nominal Current: 50 uA

Failsafe Current: 180 uA

Resolution: 100 mΩ

Accuracy: ± .02% of reading & range


Range: 200K Ω

Nominal Current: .05 uA

Failsafe Current: 22 uA

Resolution: 10 Ω

Accuracy:  ± .02% of reading & range



Display: 4 1/2 digit LED

Termina: Trident

Temperature Coefficient: .1 x Accuracy per 1°C

Operating Temperature Range: 0° to 50° C

Dimensions: 11.5″ x 13.5″ x 6″

Weight: 10 lbs.

Power: 4 ea rechargeable 5AH NICAD batteries

Max Input Voltage: 250 VDC

Open Circuit: 1.6 VDC

Max Failsafe Current: 8 mA
