FLUKE FLUKE-408/CNAP Laser Distance Meter (FLUKE-408, 0.2 to 80 m)
Manufacturer: FLUKE Model: FLUKE-408/CNAP P/N: 5301261 Origin: China - Contact
- In stock: 8 Unit
See more: Equipment Calibration-Inspection & Repair Service
Call for the best priceHanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Range: 0.2 to 80 m
Accuracy* In favorable condition**: ±(2.0mm+5x10^-5 D)
Accuracy In unfavorable condition***: ±(3.0mm+29x10^-5 D)
Angle accuracy ±(0.3°+0.1°+0.01*A), A is up to ±45° in each quadrant
Angel measurement method: Electronic
Measurement unit: m / ft / in / ft+in
Display: 2.0-inch positive display
Measurements
Single measurement: Yes
Continuous measurement: Yes
Area measurement: Yes
Volume measurement: Yes
Auto Level: Yes
Auto Height: Yes
Pythagoras 2-point: Yes
Pythagoras 3-point: Yes
Add / Substrate Method: Yes
Measurement reference: Front / Tripod hole / Back / Extender
Auto-off: 3 minutes after inactivity
Data Storage: 100 sets
Time-delay measurement: Yes
Auto calibration: Yes
Side button: Yes
Extender: Yes
General
Laser class: Class 2
Laser type: 630 to 670nm, <1mW
Battery life: up to 3500 measurements (single measurement)
Operating temperature: 0 ℃ to 40 ℃
Storage temperature: -10℃ to 60℃
Ingress protection: IP65
Drop test: 1 m
Size: 52 mm × 116mm × 28mm
Weight: 110g
* Temperature for specified accuracy is 25°C
** Favorable conditions: white and diffuse reflection objects (white painted walls) ,low background illumination and moderate temperature
*** Unfavorable conditions: objects with low or high reflectivity, high background illumination or the temperature is at the upper or lower limit of the specific temperature range
Certification
Laser certification: IEC 60825-1: Class 2, 635 nm, <1 mW
CPA, CE
Electrical certification: IEC 61010-1: Pollution Degree 2
EMC: IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A
Package
Packaging box: Full telescope
User manual
Vinyl Carrying pouch
Battery 2 AAA NiMH rechargeable cells
Qualification certificate
Lanyard
Charging cable Type-C cable, 0.5m
Datasheet
Manual
Model | Fluke 404E | Fluke 406E | Fluke 405 | Fluke 408 | Fluke 410 |
---|---|---|---|---|---|
Specifications | |||||
Range | 0.2 to 40 m | 0.2 to 60 m | 0.2 to 50 m | 0.2 to 80 m | 0.2 to 100 m |
Accuracy* in favorable condition** | ±(2.0mm+5x10-5D) | ±(2.0mm+5x10-5D) | |||
Accuracy in unfavorable condition*** | ±(3.0mm+29x10-5D) | ±(3.0mm+29x10-5D) | |||
Angle accuracy | ±(0.3°+0.1°+0.01*A), A is up to ±45° in each quadrant | ||||
Angel measurement method | Electronic | ||||
Measurement unit | m / ft / in / ft+in | ||||
Display | 1.6 inch, segment alphanumeric display | 2.0-inch positive display | |||
* Temperature for specified accuracy: 25°C ** Favorable conditions: white and diffuse reflection objects (white painted walls) ,low background illumination and moderate temperature *** Unfavorable conditions: objects with low or high reflectivity, high background illumination or the temperature is at the upper or lower limit of the specified temperature range | |||||
Measurements | |||||
Single measurement | ● | ● | ● | ● | ● |
Continuous measurement | ● | ● | ● | ● | ● |
Area measurement | ● | ● | ● | ● | ● |
Volume measurement | ● | ● | ● | ● | ● |
Auto Leveling | ● | ● | ● | ● | ● |
Auto Vertical | ● | ● | ● | ● | ● |
Pythagoras 1 | ● | ● | ● | ● | ● |
Pythagoras 2 | ● | ● | ● | ● | ● |
Plus-minus method | ● | ● | ● | ● | ● |
Measurement reference | Front / Back | Front / Tripod hole / Back / Extender | |||
Auto-off | 3 minutes after inactivity | 3 minutes after inactivity | |||
History measurement data | 30 sets | 100 sets | |||
Time-delay measurement | ● | ● | ● | ||
Auto calibration | ● | ● | ● | ||
Side button | ● | ● | ● | ||
Extender | ● | ● | ● | ||
General | |||||
Laser class | Class 2 | ||||
Laser type | 630 to 670nm, <1mW | ||||
Battery life | up to 5000 measurements (single measurement) | up to 3500 measurements (single measurement) | |||
Operating temperature | 0 C° to 40 C° | ||||
Storage temperature | -10 C° to 60 C° | ||||
Ingress protection | IP54 | IP65 | |||
Drop test | 1 m | 1 m | |||
Size | 50 mm × 115mm × 29mm | 52 mm × 116mm × 28mm | |||
Weight | 100g | 110g | |||
Certification | |||||
Laser certification | IEC 60825-1: Class 2, 635 nm, <1 mW CPA, CE | ||||
Electrical certification | IEC 61010-1: Pollution Degree 2 EMC: IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A | ||||
Packaging and accessories | |||||
Packaging box | Folding box | Folding box | Full telescope | Full telescope | Full telescope |
User manual | √ | √ | √ | √ | √ |
Vinyl carrying pouch | √ | √ | √ | √ | √ |
Battery | 2 AAA alkaline cells | 2 AAA alkaline cells | 2 AAA NiMH rechargeable cells | 2 AAA NiMH rechargeable cells | 2 AAA NiMH rechargeable cells |
Qualification certificate | √ | √ | √ | √ | √ |
Lanyard | √ | √ | √ | ||
Charging cable | Type-C cable, 0.5m | Type-C cable, 0.5m | Type-C cable, 0.5m |
