THORLABS TD4HR18XP Mounted Thermal Position Detectors (100 µW - 5 W)
Manufacturer: THORLABS Model: TD4HR18XP - Request a Quotation
- Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best priceHanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Wavelength Range: 190 nm - 20 µm
Optical Power Working Range (a): 100 µW - 5 W
Spatial Resolution: 30 µm
Active Sensor Area: 18.0 mm x 18.0 mm (0.71" x 0.71")
Max Average Power Density(b): 1.5 kW/cm²
Max Pulse Energy Density: 0.3 J/cm^2 (1 ns Pulse), 5 J/cm^2 (1 ms Pulse)
Detector Type: Four Thermopiles in Quadrant Configuration
Min Responsivity, Each Quadrant: 80 mV/W
Linearity with Optical Power: ±0.2%
Rise Time(c): 1.1s
Active Area Uniformity: ±1% (>1 mm Beam Diameter)
Detector Dimensions: 35.0 mm x 35.0 mm x 1.6 mm (1.38" x 1.38" x 0.06")
Substrate: PCB
Mounting(a): Four Ø3.4 mm (Ø0.13") Mounting Holes
Electrical Connection: Wire
(a) Mounting on an appropriate heat sink is required. For mounting instructions and other information, see the Handling Instructions manual.
(b) Damage Threshold
(c) Typical Natural Response Time (0 - 95%)
