WMT CNC CK42L Slant Bed CNC Lathe (480mm)

Max.swing over bed: Ф480mm

Max.swing over cross slide: Ф350mm

Max.maching diameter(disk/rod): Ф320mm/Ф80mm

Max.length of work piece: 420mm

spindle bearing diameter: Ф100

Spindle bore diameter: Ф62mm

Spindle bore taper: 80mm

Spindle nose: A2-6

Spindle speed range: 60-3800r/min

Power of the main motor: 7.5-11kw

Min.input unit: 0.0005/0.001mm

Rapid speed: 20/20m/min

Hydraulic chuck: 8″

Hydraulic station: 8

Max.dia for boring size: Ф32

Quill diameter: Ф80mm

Quill travel: 80mm

Packing size: 2220x1405x1640mm

N.W/G.W: 3800/4200kg
