Doble PCI-600 Primary Current Injection (100 mA – 1000 A)

PHYSICAL SPECIFICATIONS

16.8”W x 12.6”H x 10.6” D (42.6 cm by 32.0 cm by 27 cm); Weight: 46lbs (21kg)

INPUT POWER: 100 – 120 Vac or 200 – 240 Vac (factory pre-set), 50/60 Hz

INTERNAL CURRENT METER: 100 mA – 1000 A; Accuracy: 1% of reading, ±20 mA

MEASURING METHOD: Isolated CT

EXTERNAL METER RANGE: 10 mA – 10 A; Accuracy: 1% of reading, ±2 mA

MEASURING METHOD: Isolated CT

TIMER READING RANGE: 1 ms – 2 hours; Accuracy: 0.1% of reading ±1ms
