ESCO AC3-5B1 Biological Safety Cabinet (430W, 220-240VAC, 50Hz, 0.8m²)

Nominal size: 1.5m

External Dimensions (W x D x H): 1995 x 850 x 2270 mm

Internal Work Area, Dimensions (W x D x H): 1430 x 560 x 635 mm

Internal Work Area, Space: 0.80 m²

Number of Gloves Ports: 4 ports

Glove Type & Sizes Available: NeopreneTM polychloroprene synthetic rubber gauntlets.

Available in sizes: 7, 8 (standard size) and 9

Initial Airflow Volume: 756 m3 /h

Minimum Required Negative Pressure: -200 Pa (0.8" Wg)

Nominal Required Negative Pressure: -275 Pa (- 1.1" Wg)

Pre-Filter: Disposable and non-washable polyester fibers with 85% arrestance / EU3 rated

ULPA Filter Typical Efficiency (Downflow, 1st Exhaust, 2nd Exhaust): Typical: 99.999% at 0.1 to 0.3 μm and MPPS

Sound Emission (Typical)

NSF 49: <62 dBA

EN 12469: <59 dBA

Fluorescent Light Intensity At Zero Ambient: > 800 lux (74 foot candles)

Cabinet Construction

Main Body: 1.5 mm (0.06") 16 gauge electro-galvanized steel with white oven-baked epoxy-polyester Isocide™ antimicrobial powder coated finish

Work Zone: 1.2 mm (0.05") 18 gauge stainless steel, type 304, with 4B finish

Electrical: 220-240V, AC, 50Hz, 1Ø

Cabinet Full Load Amps (FLA): 3 A

Cabinet Nominal Power: 430 W

Net Weight: 598 kg
