KIKUSUI PLZ164WL High Speed-Large Current DC Electronic Load (30V, 50A, 160W)

Operating voltage (DC): 0.3V ~ 30 V

Current: 50A

Power: 165 W

- CC mode

Setting range:

Range H: 0 A ~ 52.5A

Range M: 0 A ~ 5.25A

Range L: 0 A ~ 525 mA

Setting accuracy: ±(0.2 % of set + 0.1 % of f.s) + Vin/ 150 kΩ

Ripple: rms: 4 mA/ p-p: 40mA

- CR mode

Setting range

H: 173.25 S ~0 S

M: 17.325 S ~ 0 S

L: 1.7325 S ~0 S

Setting accuracy: ±(0.5 % of set + 0.5 % of f.s) + Vin/ 150 kΩ

- CV mode

Setting range:

H: 0 V ~ 31.5 V

L: 0 V ~ 4.2 V

Setting accuracy: ±(0.2 % of set + 0.2 % of f.s)

- CP mode

Setting range:

Range H: 0 W ~ 173.25 W

Range M: 0 W ~ 17.325 W

Range L: 0 W ~ 1.7325 W

Setting accuracy: ±(2.5 % of f.s )

Measurement function: V, A, P

Other functions: Sequence, Remote sensing, Protection function (OVP, OCP, OPP, UVP)

Communication: GPIB, RS232C, USB

Accessories:

Power cord × 1 pc. (with plug, Length: approx. 2.4 m),

Load input terminal cover × 1 piece (2 lock plates provided),

Set of screws for the load input terminal × 2 sets (bolts, nuts, and spring washers),

Setup guide × 1 piece(Japanese, English),

Quick Reference(Japanese:1 piece, English:1 piece), CD-ROM × 1 piece
