Rated input power: 1000 W
Output power: 520 W
Max. drill-Ø with core drill: 32 mm / 1 1/4 "
Max. drill-Ø with spiral drill: 13 mm / 1/2 "
Maximum drilling depth: 50 mm / 2 "
No-load speed: 700 rpm
Revolutions at rated load: 450 rpm
Bit retainer: Weldon shaft 19 mm (3/4")
Weight: 11.9 kg / 26.2 lbs
Cable length: 5 m / 16 ft
Torque: 50 Nm / 443 in-lbs
Max. depth of feed: 160 mm / 6 5/16 "
Max. magnetic holding force: 12250 N
Dimensions of the magnet base: 90 x 189 mm / 3 9/16 x 7 1/2 "
Height carriage lowest position: 343 mm / 13 1/2 "
Height carriage topmost position: 490 mm / 19 9/32 "
Drilling in metal: 2.5 m/s²
Uncertainty of measurement K: 1.5 m/s²
Sound pressure level: 85 dB(A)
Sound power level (LwA): 98 dB(A)
Uncertainty of measurement K: 3 dB(A)
Ejector pin 75 mm
Swarf protection guard
Hexagon socket wrench SW 4
Core drills, Further accessories for core drills
Large stroke, therefore suitable for use of core drills, spiral drills and countersinks
Magnetic base with high holding power permits working on vertical surfaces and overhead
Robust Metabo marathon motor with internal wiring for long service life
Integrated coolant container for easy to dose internal cooling of the core drill
Bright LED light for easy alignment in poor light conditions
Swarf protection can be fixed without tools and protects the user from metal shavings and tool contact
Protective circuit starts motor only if the magnet is activated
Restart protection: prevents unintentional start-up after power supply interruption
Lockable slide for comfortable tool change
Handle for easy carrying and lifting
Resistant mains cable (5 m) with rubber shroud
