Telide PTP-1L 便携式气体和液体安全阀试验台 (15/30MPa)

Max.test pressure:

    Gas:15MPa

    Liquid: 30MPa

Clamping range: Flanged:DN15-150(1/2”-6”) ; Threaded:DN15-50(1/2”-2”)

Clamping force: 6T,Manual clamping

Test medium: Nitrogen, compressed air ,water

Maximum height under the claws: 60mm

Clampable min. flange outer diameter: 75mm

Clampable max. flange outer diameter: 300mm

Power request: Test gas source: bottled nitrogen(≤15MPa)

Clamping seat: Single seat

Standard Configuration

    Nitrogen cylinder hose(L=3m): 1pcs

    O-ring for test: 2set

    liquid inlet hose and outlet hose(L=5m) : 1pcs of each

    Funnel(for adding water to water tank): 1pcs

    Flange-thread transition plate(φ160mm): 1pcs

    Tool kit: 1pcs

    Threaded safety valve adapter,each 1pcs from DN15-50: Total 6pcs
