Input power:0W to 1000W
Input voltage V:0V to 150V
Input current:0A to 200A
Full-color 3.5 inch LCD provides high operability and visibility.
10μA minimum resolution for current setting (LSA-165 L range).
CC/CR/CP/CC+CV/CR+CV mode are selectable.
High-speed response for 10μsec. Switching function is available (CC, CR, CP mode).
External voltage / resistance control function is available.
Maximum 5-unit-parallel master-slave operation is available.
Sequence control provides branch on condition.
Maximum Dimmension(mm) 140.8×423.3×449
Option: GP-IB, USB and RS-232C are in one slot-in option board IF-80GUR.Recommend to use GP-IB or RS-232C if you use LSA series at noisy condition.
