Trotec PRDS 10‑20V Cordless Hammer Drill (0 - 5000 min-1; 1 Joule)

Technical data:

Number of speed levels: 1

Idle speed 1. Speed level: 0 - 900

Impact frequency combined 1. Speed level: 0 - 5.000 min-1

Impact energy [Joule]: 1

Maximum drilling diameter:

Wood [mm]: 16

Metal [mm]: 8

Concrete / brickwork max. [mm]: 10

Sound values according to EN 60745:

Sound pressure level [dB(A)]: 82.38

Sound power level [dB]: 93.38

Uncertainty K [dB]: 3

Vibration information according to EN 60745:

Vibration emission value (ah) Hammer drilling in concrete (main handle) [m/s²]: 6.314

Uncertainty (K) Hammer drilling in concrete (main handle) [m/s²]: 1.5

Vibration emission value (ah) Hammer drilling in concrete (additional handle) [m/s²]: 4.58

Uncertainty (K) Hammer drilling in concrete (additional handle) [m/s²]: 1.5

Electrical values battery:

Battery nominal voltage [V]: 20

Battery capacity [Ah]: 2

Capacity indication: 3-stage

Battery type: Li-ion

Battery charging time [h]: 1

Charger:

Mains connection: 230 - 240 V, 50 Hz

Output voltage [V]: 21.5

Power input [W]: 65

Nominal current consumption [mA]: 2400

Connection plug: CEE 7/16

Cable length [m]: 1.5

Protection class: II

Dimensions:

Length (packaging excluded) [mm]: 238

Width (packaging excluded) [mm]: 84

Height (packaging excluded) [mm]: 250

Weight:

(packaging excluded) [kg]: 1.5
